Home > ASTM A182 F60 Fasteners
Request For Our Latest Prices On ASTM A182 F60 Fasteners in Muscat, OMAN!
Mazin Fasteners, located in Muscat, Oman, has earned a solid reputation as a reliable manufacturer and supplier of top-notch industrial fasteners, including the ASTM A182 F60 fasteners. These fasteners are crafted to adhere to strict international standards, guaranteeing precision, strength, and dependable performance in tough industrial settings. Built to thrive in high-temperature and high-pressure situations, ASTM A182 F60 fasteners find their way into various industries like oil and gas, petrochemical, power generation, and heavy engineering. Thanks to advanced manufacturing techniques and rigorous quality control, Mazin Fasteners provides fastening solutions that ensure durability, safety, and long-lasting operational reliability.
Made from alloy steel with a carefully balanced chemical composition, ASTM A182 F60 fasteners boast impressive tensile strength, toughness, and resistance to oxidation even at elevated temperatures. They undergo heat treatment to enhance their mechanical properties, resulting in better yield strength and fatigue resistance. Their exceptional strength and durability make them perfect for critical applications in pressure vessels, boilers, and high-temperature industrial equipment, where safety and performance are non-negotiable.
| Identification Symbol | UNS Number | Grade | Elements | Composition % |
|---|---|---|---|---|
| F60 | S32205 | 22 chromium, 5.5 nickel, 3 molybdenum, modified with nitrogen 2205 | Carbon | 0.030 max |
| Manganese | 2.00 max | |||
| Phosphorus | 0.030 max | |||
| Sulfur | 0.020 max | |||
| Silicon | 1.00 max | |||
| Nickel | 4.5 – 6.5 | |||
| Chromium | 22.00 – 23.00 | |||
| Molybdenum | 3.00 – 3.5 | |||
| Nitrogen | 0.14 – 0.20 |
| Property | Value |
|---|---|
| Tensile Strength, min, ksi [MPa] | 95 [655] |
| Yield Strength, min, ksi [MPa] | 65 [450] |
| Elongation in 2 in. [50mm] or 4D, min, % | 25 |
| Reduction or Area, min, % | 45 |
| Brinell Hardness Number, HBW | — |
| Standard | ASTM, BS, ASME, ISO, UNI, ANSI, GB, IS, DIN, JIS Fasteners |
|---|---|
| Threads: | BSF, BSW, UNF, UNC, METRIC or as per need |
| Astm A182 Grade F60 Bolts Standard | ANSI
|
| ASTM A182 GR. F60 Fasteners / Bolts Size | M6, M30, M12, M10, M16, (M45), M4, M8, M2, M24, (M3.5), M33, M20, M42, (M14), M5, M48, (M18), (M27), (M22), M36, M3, M160 and as per need |
| Length | 3 milimeter – 200 milimeter |
| Head drive: | Slotted, Six-Lobe, Phillips/Slot, Phillips, etc |
| Bolts Test Certificate | EN 10204 / 3.1 |
| Duplex Grade F60 Fasteners raw materials of Source | Usha Martin, JSPL, Mukund Steel, Tata Steel, Dhamm Steel, RINL etc. |
| Form | Square, Hex, Threading as per Gauge, Round Etc. |
| Astm A182 Grade F60 Bolts Process of Production |
|
| Duplex Steel Gr F60 Fasteners Surface Coating |
|
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
ASTM A182 F60 fasteners are utilized across industries requiring exceptional corrosion resistance and mechanical strength. They find application in demanding environments such as offshore oil rigs, chemical processing plants, and marine structures. These fasteners are crucial for securing critical components where resistance to chloride-induced stress corrosion cracking is vital. With their high tensile strength and durability, ASTM A182 F60 fasteners ensure reliable performance in harsh conditions, making them preferred choices for ensuring structural integrity and longevity in challenging operational settings.
You’ll often find ASTM A182 F60 fasteners in flanged joints, pipelines, pressure vessels, valves, and heat exchangers that operate under high-temperature and high-pressure conditions. They’re particularly suited for chemical plants, refineries, power stations, and other industrial facilities where strength, durability, and resistance to thermal and mechanical stress are crucial. With their reliable performance and extended service life, these fasteners are the go-to choice for engineers and contractors looking for secure and efficient bolted assemblies in demanding environments.
